Double Sides Full Color Outdoor Advertising Led Display Front Open Service AC 220V

Double Sides Full Color Outdoor Advertising Led Display Front Open Service AC 220V
Double Sides Full Color Outdoor Advertising Led Display Front Open Service AC 220V Double Sides Full Color Outdoor Advertising Led Display Front Open Service AC 220V Double Sides Full Color Outdoor Advertising Led Display Front Open Service AC 220V

Large Image :  Double Sides Full Color Outdoor Advertising Led Display Front Open Service AC 220V

Product Details:
Place of Origin: China
Brand Name: Shenzhen LED World
Certification: CE,RoHS,FCC,CCC
Model Number: LW-FO8
Payment & Shipping Terms:
Minimum Order Quantity: 1 Square Meter
Price: Negotiable
Packaging Details: Carton/Plywood case/Flight case etc.
Delivery Time: 12~18 days after receiving the deposit
Payment Terms: T/T, Western Union
Supply Ability: 5000 Sqm/Month
Detailed Product Description
Level Of Gray: 65536 Level Of Brightness/Color: RGB256
Frame Frequency (HZ): ≥60 HZ/Sec Refresh Frequency (HZ): ≥600 Hz/Sec
Driving Components: Constant Current Driving Scan And Control Method: 1/4 Synchronous Control
Max Consumption(W/m²): ≤760 W/m² Average Power Consumption(W/m²: ≤380 W/m²
Working Voltage(V): AC220V±10% Relative Humidity: 10%-95%
High Light:

led full color screen

,

commercial led display

Waterproof 50kg Double Sides Outdoor Led Display For Customized Front Open Service





What is Front Service?

There are many ways to install LED display screen, some occasions are suitable for making steel structure around the edge, some occasions are only suitable for wall installation, if only wall installation, maintenance is a headache, that is to say, can only face maintenance, we define the front maintenance structure





Double Sides Outdoor Led Display Features:

  • Ultra power-saving design: each squared average power consumption control at about 200W, than peers of similar products saving more than 50% each year for the owner saving about eight million
  • Waterproof module with enclosed structure;
  • the box body can be both before and after the maintenance, no maintenance access may also install, save space and cost, improve work efficiency;
  • With IP65 rating standard, which ensure its normally working under heavy raining environment

  • Product has strong ability to anti-surge, anti-static and anti lightning stroke;
  • Advanced control system: Prefer adopting advanced and stable Nova Star control system, with the best-led display control system, the most advanced pixel-level led display calibration system and the most professional software for specialized applications.

Double Sides Outdoor Led Display ​Parameter:



Module Parameter NO. P8
Size of Module(mm) 256*128
Pixel Density(dots/m²) 15625 dots/m²
Pixel Pitch(mm) 8mm
LED Encapulation SMD3535
Resolution of Module(dots) 32(W)*16(H)
Thickness of Module (mm) 17.05(No magnet)
Weight of Module (Kg) 0.343
Driving Method Constant Current Driving
Equilibrium Brightness(CD//m²) ≥6500 CD/m²
Bracket Size(mm) 256*128
256*256
Cabinet Size of Cabinet(mm) 768*768
512*512
Power Supply Mode 5V/40A*1PC
Best Viewing Distance(m) 8-100m
Best Viewing Angle 160(W) 120(H)
Storage Temperature(ºC) -35ºC ~ +85ºC
Working Temperature(ºC) -40ºC ~ +50ºC
Relative Humidity 10%-95%
Power Supply Working Voltage(V) AC220V±10%
Average Power Consumption(W/m²) ≤380 W/m²
Max Consumption(W/m²) ≤760 W/m²
Control System Scan and control Method 1/4 Synchronous Control
Driving Components Constant current Driving
Technical Parameters Refresh Frequency (HZ) ≥600 Hz/Sec
Frame Frequency (HZ) ≥60 HZ/Sec
Level of Brightness/Color RGB256
Level of Gray 65536
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.





Our service:

  • Other services, such as special packing design, factory visiting and so on;
  • WealsoprovidelifetimeconsultationbyE-mail,call,MSNorotherways for free;
  • Documents and Certification
  • Two years warranty,also prvide you free spare parts such as modules, power supply ,LED lamps,lines etc;
  • OEM design cabinet for customers , different colors and thickness ,shape;
  • 24/7 hours after service;
