Front Access High brightness Advertising LED Displays P10 DIP wall Mounted

small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Front Access High brightness Advertising LED Displays P10 DIP wall Mounted

Product Details:
Place of Origin: China
Brand Name: Shenzhen LED World
Certification: CE,RoHS,FCC
Model Number: LW-FO 10
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: Negotiation
Packaging Details: Carton/Plywood case etc.
Delivery Time: 12-20 working days after received your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 3,000 square meters per month
Detailed Product Description
View Angle / °: 110 H,60 V IP Rating: Front,IP65;Rear,IP43
Control System: Linsn / Nova(sending Card,receiving Cards And Hubs) Led Encapsulation: DIP346
Module Size/mm: 160x160 Grey Scale/color: Displaying Colors≥16.7M(synchronized)
Density Of Pixel/(dots/m2): 10,000 Size Of Cabinet/mm: 960X960
High Light:

led outdoor advertising screens


advertising led display screen


Front Access High brightness Advertising LED Displays P10 DIP wall Mounted

Our full color LED display are widely used in concert,propaganda image,bus station,Indoor stage,trade fair,movie theater,athletic contest,gym,internal,conference video center, Lobby,bar,TV Shows,
commercial building and so on .

  • Durable fresh color and high brightness by adopting high quality LEDs;
  • Support text, image, animation and video;
  • Supports full front maintenance. Power supply and receiving card can be taken off and replaced in front of cabinet for maintenance by which you can use more convenient;
  • 4096 grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor, whose scope is 256 grade;
  • Brightness variances within +/-2.5%, pixel calibration before delivery;
  • Good Ventilation
  • Its transmittance is over 7% and gain the homogeneous emission. No fans, no air conditioning and save cost;
  • Cabinet design standardized makes the same cabinet dimension applicable to different requirements of display pixels, make installation for advertising screens more convenient. Reasonable circuit wiring makes the quality stability and reliability. The fans inside the unit cabinet can accelerate cooling;
  • Can be used outdoor in all kinds of weather, and excellent capability of antisepsis, waterproof;
  • IP65 for front,and IP54 for back , good waterproof, can be used for outdoor when it is raining;



Outdoor Fixed Installed Giant Advertising Media LED Displays
Main Pitch/mm P10
Module size/mm 160x160
Density of pixel/(dots/m2) 10,000
Pixel composition 1R1G1B
Led encapsulation DIP346
Resolution of module 16X16
Optimum viewing distance ≥10
View angle / ° 110 H,60 V
Average power consumption/W/M2 450
Max power consumption/W/M2 950
Size of cabinet/mm 960X960
Resolution of cabinet 96X96
Driving method 1/4 scan constant current
Refresh rate Hz/S ≥1200
Luminance of white balance ≥7500 nits
Operation of Environmental Temperature/℃ below 30 to above 50
IP rating Front,IP65;Rear,IP43
Working voltage 110-220 VAC/+/- 10%
Grey scale/color displaying colors≥16.7M(synchronized)
Brightness adjustment 4096 levels of each color(manually),100 levels of each color(automatically)
Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system Linsn / Nova(sending card,receiving cards and Hubs)
Average of non-failure life >50,00h
Life span >100,000h
Functionless dot rate <0.0001
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.


  • Are you manufacturer or trading company?
  • We are manufacturer with professional marketing and service team;
  • Besides this product, may I have other options?
  • Yes, my dear friend. Many thanks for finish the details of this product. If it is not what you're looking for, you can also choose other items. we have HD indoor led display, full color for outdoor and indoor; Different cabinet, Steel Cabinet, Aluminum Cabinet, Die Cast Aluminum Cabinet, etc; The pixel pitch is from 1.5mm to 20mm. We also have LED advertising player and kinds of video processor;
  • Are you manufacturer of led display.If yes, in which city?
  • Yes, Our factory with 9000 square meters. And we're in SHENZHEN city, GUANGDONG Province;
