Pixel Pitch(mm): | 1.667 | Pixel Density(dots/㎡): | 360000 |
---|---|---|---|
Flatness Error(mm): | ≤0.1 | Contrast: | 5000:01:00 |
Driving Mode: | Constant Current Driver, 1/30 Scanning | Power Requirements: | AC90~264V, 47~63Hz |
Life Time(hrs): | 50,000 | Ave. Power(W/㎡): | 240 |
High Light: | Hd Led Screen,Led Big Screen |
Inside P1.667 LED Video Screen High Definition 160/160° Viewing Angle
P1.667 LED Video Screen features:
High refresh, high gray level. The high-refresh IC chip used in the cabinet configuration makes display effect more delicate and realistic.
Low temperature and silver welding process, welding more plump, promoting product stability effectively.
Solid aluminum structure to meet the all requirements of time or assemble and disassemble.
Different signal resources input are all acceptable, such as TV HCTV S-video NTSC PAL DVI AVI VGA SDI MOV MPG etc
P1.667 LED Video Screen parameter:
Module | Model | LW-FI1.66 |
Pixel pitch(mm) | 1.667 | |
Configuration | SMD1010 | |
module resolution | 120x90 dots | |
Module weight(kg) | 0.4 | |
Module dimension(mm) | (W)200x(H)300 | |
Cabinet | Panel dimension(mm) | (W)400x(H)300x(T)66 |
cabinet resolution | 240x180 dots | |
Installation type | Fix | |
Panel weight(kg) | 4.6 | |
Electricity parameter | Pixel density(dots/㎡) | 360000 |
Flatness error(mm) | ≤0.1 | |
Viewing angle(°) | 160/160(Horizontal/Vertical) | |
Brightness(cd/㎡) | ≥700 | |
Color temperature(K) | 3200~9300 (Adjustable) | |
Contrast | 5000:01:00 | |
Repetition frequency(Hz) | 50/60 | |
Refresh frequency(Hz) | ≥2000 | |
Gray scale(bit) | 16 | |
Ave. power(W/㎡) | 240 | |
Max power(W/㎡) | 1000 | |
Panel structure | Die-casting aluminum | |
Maintenance | Rear | |
Brightness/color correction | Yes | |
Driving mode | Constant current driver, 1/30 scanning | |
Power requirements | AC90~264V, 47~63Hz | |
Signal Transmission Distance | CAT cable:<100m;Single mode fiber:<10km | |
Working temp./humidity | -10~40℃/10%~80%RH | |
Storing temp./humidity | -20~60℃/10%~85%RH | |
Life time(hrs) | 50,000 | |
Certificate | CCC/TUV-CE/ETL, etc. | |
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. |
