DVI VGA HDMI P5 P6 P8 Full Color LED Display Board RGB256 Low Power Consumption

DVI VGA HDMI P5 P6 P8 Full Color LED Display Board RGB256 Low Power Consumption
DVI VGA HDMI P5 P6 P8 Full Color LED Display Board RGB256 Low Power Consumption DVI VGA HDMI P5 P6 P8 Full Color LED Display Board RGB256 Low Power Consumption

Large Image :  DVI VGA HDMI P5 P6 P8 Full Color LED Display Board RGB256 Low Power Consumption

Product Details:
Place of Origin: China
Brand Name: Shenzhen LED World
Certification: CE,RoHS,FCC,CCC
Model Number: LW-FO 5
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: negotiable
Packaging Details: Carton/Plywood case etc.
Delivery Time: 10~20 days after receiving the deposit
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5,000 square meters per month
Detailed Product Description
Thickness Of Module (mm): 17.05(No Magnet) Level Of Brightness/Color: RGB256
Average Power Consumption(W/m²): ≤500 W/m² Best Viewing Angle: 160(W) 120(H)
Usage: Outdoor Tube Chip Color: Full Color
Display Function: Video,Animation,Graphics Warranty: 1year/2year/5year
Life Span: 100000hours Led Chip: NationstarSMD2727
High Light:

led full color screen

,

commercial led display





DVI VGA HDMI P5 P6 P8 Commercial Outdoor LED Display Board Low Power Consumption



P5 , P6 , P8 Outdoor Fixed LED Display features:

  • Direct low voltage power supply, low heat, no noise;
  • Easy to installation and maintain;
  • Cushion under the cabinet can protect the modules from being damaged;
  • LED display have good waterproof and anti-humidity when used;
  • Incorporating high-quality luminescent of RED, GREEN BLUE
  • LED elements and a large number of pixels enables a brilliant display even in direct sunlight, and a wider viewing angle;
  • Stable cabinet, stronger without distortion, anti-rust;

P5 , P6 , P8 Outdoor Fixed LED Display parameter:

Module Parameter NO. P5 P6 P8
Size of Module(mm) 320*160 192*192 256*128
Pixel Density(dots/m²) 40000 dots/m² 27777 dots/m² 15625 dots/m²
Pixel Pitch(mm) 5mm 6mm 8mm
LED Encapulation SMD2727 SMD3535 SMD3535
Resolution of Module(dots) 64(W)*32(H) 32(W)*32(H) 32(W)*16(H)
Thickness of Module (mm) 17.05(No magnet) 17.05(No magnet) 17.05(No magnet)
Weight of Module (Kg) 0.5 0.369 0.343
Driving Method Constant Current Driving Constant Current Driving Constant Current Driving
Equilibrium Brightness(CD//m²) ≥7000 CD/m² ≥7000 CD/m² ≥6500 CD/m²
Bracket Size(mm) 160*160 192*192 256*128
320*160 384*192 256*256
Cabinet Size of Cabinet(mm) 640*640 576*576 768*768
512*512
Power Supply Mode 5V/40A*1PC 5V/40A*1PC 5V/40A*1PC
Best Viewing Distance(m) 5-100m 6-100m 8-100m
Best Viewing Angle 160(W) 120(H) 160(W) 120(H) 160(W) 120(H)
Storage Temperature(ºC) -35ºC ~ +85ºC -35ºC ~ +85ºC -35ºC ~ +85ºC
Working Temperature(ºC) -40ºC ~ +50ºC -40ºC ~ +50ºC -40ºC ~ +50ºC
Relative Humidity 10%-95% 10%-95% 10%-95%
Power Supply Working Voltage(V) AC220V±10% AC220V±10% AC220V±10%
Average Power Consumption(W/m²) ≤500 W/m² ≤500 W/m² ≤380 W/m²
Max Consumption(W/m²) ≤1000 W/m² ≤1000 W/m² ≤760 W/m²
Control System Scan and control Method 1/8 Synchronous Control 1/8 Synchronous Control 1/4 Synchronous Control
Driving Components Constant current Driving Constant current Driving Constant current Driving
Technical Parameters Refresh Frequency ≥1920 Hz/Sec ≥1920 Hz/Sec ≥1920 Hz/Sec
(HZ)

Frame Frequency ≥60 HZ/Sec ≥60 HZ/Sec ≥60 HZ/Sec
(HZ)
Level of Brightness/Color RGB256 RGB256 RGB256
Level of Gray 65536 65536 65536
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.





Why choose us:

  • Own Unique Design LED Screen;
  • More than hundreds of workers and using technical equipment;
  • We are expert in rental LED display , we have many ultra-thin super-light panel designs for your choice;
  • With special rigging system It is very convenient to hang the screen to truss It is very safe;
  • Aluminum backcover is good for heat dissipation no need a separate fan inside it is very quiet for some events that requests very quiet environment;
  • Your inquiry related to our products or prices will be replied in 24hrs;
  • LED World has 7 years of export experience;

DVI VGA HDMI P5 P6 P8 Full Color LED Display Board RGB256 Low Power Consumption 0DVI VGA HDMI P5 P6 P8 Full Color LED Display Board RGB256 Low Power Consumption 1

P5 , P6 , P8 Outdoor Fixed LED Display package:



DVI VGA HDMI P5 P6 P8 Full Color LED Display Board RGB256 Low Power Consumption 2
