Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 4mm | LED Lamp: | SMD2020 |
|---|---|---|---|
| Module size: | L128*H128 | Pixel resolution: | 64x64=4096 |
| Pixel Configuration: | 1R1G1B | Brightness: | 3000 Cd/sqm |
| Refresh Frequency: | >1920HZ | Cabinet Weight: | 50Kg |
| Pixels Density: | 62500 Dot/m2 | Max. Power Consumption: | 720 W/m2 |
| High Light: | 4mm Pixel Full Color Led Signs,SMD2020 Full Color Led Signs,1R1G1B Led Advertising Display Board |
||
HD Full Color Led Signs For Advertising And High Brightness With The Fast Lock
HD Light Screen With Single Pole Features:
A: Intelligent control
With The LAN, WIFI,3G Intelligent management core modules inside. The advertisement show can be changeable.
WIFI,3G/4G
B. Time and Labor-saving
Once it is successfully installed, Its advertising content can be changed at any time. Unlike those traditional static billboards which need to be disassembled frequently. It is of high Time and labor-saving.
C. High IP level
With front/back IP level 65/54. The screen can be used outdoor even against terrible weather.
D. Easy maintenance
Side-Open and back-open maintenance render it more optional installation positions.
HD Light Screen With Single Pole Parameters:
| Part Number | S68-I3 | S68-I4 | S68-I5 | S68-I6 |
| Pixel Pitch | 3 mm | 4 mm | 5 mm | 6 mm |
| LED Configuration | SMD2020 | SMD2020 | SMD2727 | SMD2727 |
| Pixel Density | 111111 dot/m2 | 62500 dot/m2 | 40000 dot/m2 | 27777 dot/m2 |
| Module Size | 192×96 mm | 128×128 mm | 160×160 mm | 192×192mm |
| Module Resolution | 64×32 dot | 32×32 dot | 32×32 dot | 32×32dot |
| Cabinet Size | 888×1600 mm | 894×1606 mm | 800×1600 mm | 768×1412mm |
| View Size | 768×1344 mm | 768×1280 mm | 800×1280 mm | 768×1152 mm |
| Cabinet Resolution | 256×448 dot | 192×320 dot | 160×256 dot | 128×192 dot |
| Cabinet Weight | 60 kg | 50 kg | 65kg | 45 kg |
| IP Rating (front/ back ) | IP 65/43 | IP 65/43 | IP 65/43 | IP 65/43 |
| Brightness | ≥3000 cd/m2 | ≥3000 cd/m2 | ≥5000 cd/m2 | ≥5000 cd/m2 |
| View Angle | 120° | 120° | 120° | 120° |
| Gray Scale | 13 bit | 13 bit | 13 bit | 13 bit |
| Display Scale | 16.7 M | 16.7 M | 16.7 M | 16.7 M |
| Max. Power Consumption | 1300 W/m2 | 720 W/m2 | 800 W/m2 | 1000 W/m2 |
| Ave. Power Consumption | 300 W/m2 | 210 W/m2 | 280 W/m2 | 300 W/m2 |
| Refresh Frequency | ≥1920 Hz | ≥960 Hz | ≥1920 Hz | ≥1920 Hz |
| Operating Environment | OUTDOOR | |||
| Operating Power | AC 100~240V 50/60Hz | |||
| Operating Temperature | -20℃~+50℃ | |||
| Operating Humidity | 10~90%RH | |||
| Operating Life | 100,000Hours | |||
Our Service:
1.Receive the cargo
Make sure the cargo in sealing condition and the cargo storage temperature between - 30℃ and 60℃ when you receive the goods from the customs
2. Install and use the product
Please adopt a preheating model to light it up and keep 30% brightness for 0.5-2 hours when you use it. Keep it work 8 hours or above continually per day will be better. It will be better to use it at least once a week.
3. Cleaning
Ensure to use a soft brush to clean the display surface and PROHIBIT any liquid
when doing the cleaning.
Product details:
Application occasions:
1.Government commercial avenue, Commercial center street road. Park sightseeing project introduction, Local lighting display project. Community bulletin led display, bus station, construction display project, airport corridor project, railway, metro station exist projects.
2.Exhibition center, museum, library. Gymnasium, stadium, theater, university middle school, hospital, bank, and so on.
3.Hotel, restaurant. Mountain villa, commercial buildings.
4.Shopping mall, Sales lobby, Chain store.
