Product Details:
Payment & Shipping Terms:
|
| Grey Scale: | Red, Green, And Blue Each 16K | Pixel Pitch: | 6.67 |
|---|---|---|---|
| Operating Temperature: | -20℃ ~ +50℃ | Viewing Distance: | >6m |
| Drive Mode: | 1/6 | Cabinets Size: | 960x960mm |
| Module Size: | 320x320mm | Maintenance: | Front Service |
| High Light: | P6.67 Outdoor Fixed LED Display,5500nits Outdoor Fixed LED Display,SMD2727 Outdoor Led Display Boards |
||
Low Consumption Led Outdoor Display Screen P6.67 Front Service Maintenance With Alloy Die-Casting Cabinet
Product Description:
1. Replacing Malfunction Modules is easier & faster;
2. Thinner and lighter alloy die-casting cabinet;
3. No need for space at the backside of the LED display;
4. High protection grade of IP65 ;
5. All parts can change at the front.
Parameter:
| Items | P6.67mm outdoor led display |
| Pixel | 6.67mm |
| Configuration | SMD2727 |
| Pixel Density | 22,500 |
| Module Size(mm) | 320x320 |
| Pixels/Module | 48x48 |
| Cabinet Size(mm) | 960x960 |
| Pixels/Cabinet | 144x144 |
| Cabinet Weight | 30KG |
| Brightness | ≥5500cd/㎡ |
| Viewing Distance | >6m |
| Power | Max:1000 |
| Consumption(W/㎡) | Ave:325 |
| Driver Mode | 1/6 scan |
| Viewing Angle | H: 140°; V: 120° |
| Cabinet Material | Alloy die casting |
| Refresh Rate | 1920 HZ adjustable |
| LED Life | 100,000 hours |
| Supply Voltage | AC220V/60HZ; |
| Operating Temperature | -20℃ ~ +50℃ |
| Operating Humidity | 10% - 90% |
| Gray Scale | Red, Green, and Blue each 16K |
| Display Color | Full color |
| IP Rating | Front IP65 |
| Display Capability | Text, Graph, and Video |
| Notes: | Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. |
Why choose us:
LED World adheres to the business philosophy of mutual benefit and win-win, serving global customers with the mission of focusing on making screens. There are more than 30 distributors abroad. The company's led outdoor advertising has a large market share and a good reputation from the customers. The company’s led outdoor transportation products have become excellent suppliers for many well-known domestic companies.
Q: How Can We Guarantee Quality?
A: Seven quality control steps ensure your ordered screens good:
1). Suppliers are long-term cooperated large famous company.
2). Material check by professional workers and machines.
3). Debug every module.
4). 48-hour aging test for all modules before assembling.
5). Test every cabinet's function after assembling by engineers and machines.
6). 72-hour aging test for the whole screen before shipment.
7). All details final inspection again before package.
Q: What Can You Buy From US?
A: LED Display, LED Screen, LED Sign, LED modules, LED billboard, etc.
Q: Why Should You Buy From Us Not From Other Suppliers?
A: After 20 years' development, Shenzhen LED World Co., Ltd has accumulated rich experience in R&D and has first-class automated production equipment, standard clean automation production plant, and anti-static system devices.
Q: What Services Can We Provide?
A: 2-year quality warranty and life-long repairing service.
If any components need to repair or replace, you can send them back to Shenzhen
