Product Details:
Payment & Shipping Terms:
|
Refresh Rate: | 3840 HZ | Vertical Viewing Angle: | 160 |
---|---|---|---|
Cabinet Size: | 500x500mm | Average Power Consumption: | 270W |
Maximum Power Consumption: | 800 | Pixel Pitch: | 3.91mm , 4.81mm, 2.976mm |
Cabinet Weight(: | 8.5 Kg | Usage: | Advertising |
High Light: | SMD1515 Indoor Advertising Led Display,270W Indoor Advertising Led Display,Seamless Indoor Rental Led Display |
P2.9 P3.91 P4.81 Indoor Advertising Led Display Screen Which Supports Back And Front Service
Features:
Application:
Why choose us:
FQA:
Q1:Where is it used?
A1:Outdoor & rental use. Widely used for backdrop of staging event, rental business, live show, concert, etc.
Q2:What is Pixel Configuration?
A2:Pixel Configuration is the description of the consistence of a pixel, for instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.
Q3:How do you improve quality?
A3:Find problems and solve problems.
As a professional manufacturer in the LED field, we pay attention to material quality at different times and send information back to suppliers and every customer can give us feedback on any products, then we can check.
Q4:How about your production ability?
A4:We have 10 production lines with all series of automatic production machines.
Monthly production ability: 200,000pcs of led modules and 4,000sqm of assembled led displays.
Specification:
Pixel Pitch | 2.976 | 3.91 | 4.81 |
Pixel Density(dot/sqm) | 112896 | 65536 | 43264 |
LED Type | SMD1515 | SMD2121 | SMD2121 |
Module Size(mm) | 250x250 | 250x250 | 250x250 |
Cabinet Size(mm) | 500x500 | 500x500 | 500x500 |
Cabinet Weight(kg) | 8.5 | 8.5 | 8.5 |
Cabinet Resolution | 168x168 | 128x128 | 104x104 |
Cabinet Material | Diecasting Aluminum | Diecasting Aluminum | Diecasting Aluminum |
Brightness(cd/sqm) | 1000 | 1200 | 1200 |
Maximum Power Consumption | 800 | 800 | 800 |
Average Power Consumption | 270 | 270 | 270 |
Horizontal Viewing Angle(Deg) | 160 | 160 | 160 |
Vertical Viewing Angle(Deg) | 160 | 160 | 160 |
Grey Scale(bit) | 16 | 16 | 16 |
Refresh Rate(HZ) | 3840 | 3840 | 3840 |
