Product Details:
Payment & Shipping Terms:
|
| Refresh Rate: | 300-3000HZ Adjustable | Cabinet Weight(: | 25 Kg |
|---|---|---|---|
| Drive Mode: | 1/32S Or 1/16S | Display Capability: | Text, Graph, And Video |
| Maximum Power Consumption: | 800w | Pixel Pitch: | 3mm , 4mm, 5mm |
| Cabinet Size: | 576x576mm Or Customized | Configuration: | SMD 3-in-1 |
| High Light: | 800w Indoor Rgb Wall Display,Smd Indoor Rgb Wall Display,IP20 Stage LED Display |
||
P2.5 P3 P3.91 P4.81 Indoor Rgb Smd Wall Display With High Solution For Stage Use
Features
Specification
| Items | P2.5mm | P3mm | P4mm | P5mm | P6mm |
| Pixel | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Configuration | SMD 3-in-1 | SMD 3-in-1 | SMD 3-in-1 | SMD 3-in-1 | SMD 3-in-1 |
| Pixel Pitch | 2.5mm | 3mm | 4mm | 5mm | 6mm |
| Pixel Density | 160,000 | 111,111 | 62,500 | 40,000 | 27,777 |
| Module Size(mm) | 160x160 | 192x192or 192x96 | 256x128 | 160x160or 320x160 | 192x192 or 384x192 |
| Pixels/Module | 64x64 | 64x64or 64x32 | 64x32 | 32x32or 64x32 | 32x32or 64x32 |
| Cabinet Size(mm) | 960x960 or customized | 960x960 or customized | 1024x1024 or customized | 960x960 or customized | 960x960 or customized |
| Pixels/Cabinet | 384x384 | 320x320 | 256x256 | 192x192 | 160x160 |
| Cabinet Weight | 26KG | 26KG | 28KG | 26KG | 26KG |
| Viewing Distance | >2.5m | >3m | >4m | >5m | >6m |
| Power Consumption | Max: 800 | Max: 800 | Max: 650 | Max: 400 | Max: 400 |
| (W/㎡) | Ave: 240 | Ave: 240 | Ave: 195 | Ave: 120 | Ave: 120 |
| Driver Mode | 1/32S or 1/16S | 1/32S or 1/16S | 1/16S or 1/8S | 1/16S or 1/8S | 16S or 1/8S |
| Cabinet Material | Cold Rolled Steel | ||||
| Refresh Rate | 300-3000HZ adjustable | ||||
| LED Life | 100,000 hours | ||||
| Supply Voltage | AC220V/50HZ; AC110V/60HZ | ||||
| Operating Temperature | -20℃ ~ +40℃ | ||||
| Operating Humidity | 10% - 90% | ||||
| Viewing Angle | H: 120°; V: 120 | ||||
| Gray Scale | Red, Green, and Blue each 16K | ||||
| Display Color | 4096 Billion | ||||
| IP Rating | IP20 | ||||
| Display Capability | Text, Graph, and Video | ||||
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |||||
Why Choose Us
1. Good service whenever;
2. Full automatic production to control our high quality, best color consistency and get better performance.;
3. Price Advantage: We have the best competitive price at the market, also have the same even better quality;
4. OEM & ODM available;
5. Our products are the CE certified, ROHS compliant, FCC identified;
FAQ
1. What are the installation requirements of the LED display screen?
Power supply: the power supply connector must be matched for the size of the LED display screen.
220V electricity power supply, live wire, neutral/null wire, and the earth wire.
380V electricity power supply, three live wires, neutral/null wire, and the earth wire.
The intercept area of the live wire is the same as the null.
2. What are your products packing?
We provide 3 kinds of packing cases: carton paper case, wooden packing case, and flight packing case. Carton paper case for the led module; Wooden packing case for heavy iron cabinet; Flight packing case for rental aluminum die-casting cabinet.
3. How long will it take to deliver goods?
We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment
4. Can you assign an engineer to our site to guide the installation if we require it?
Yes. We have qualified and experienced engineers who are ready to service you.
5. Are you the manufacturer or trading company? And where is your factory?
We are a professional manufacturer of Led outdoor, Led indoor display, rental display,
stadium screen, stage screen, and advertising screen.
