120°Low Power Consumption LED Stage Display Easy Installation

120°Low Power Consumption LED Stage Display Easy Installation
120°Low Power Consumption LED Stage Display Easy Installation 120°Low Power Consumption LED Stage Display Easy Installation 120°Low Power Consumption LED Stage Display Easy Installation 120°Low Power Consumption LED Stage Display Easy Installation

Large Image :  120°Low Power Consumption LED Stage Display Easy Installation

Product Details:
Place of Origin: China
Brand Name: Shenzhen LED World
Certification: CE,RoHS,FCC
Model Number: LW-RI 3
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: Negotiation
Packaging Details: Plywood cartons or Flight case package
Delivery Time: 15-18 working days after received your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1,000 square meters per month
Detailed Product Description
Vertical Viewing Angle: 120° Driving Method: 1/16scanning
Refresh Frequency: 300Hz Blue Wavelength: 470±2nm
Life Span: More Than 100,000hours Maximum Power Consumption: 1200W/sqm
Module Density: 111111dots/sqm Pixel Configuration: RGB,3 In 1
High Light:

Led Stage Backdrop Screen

,

Stage Background Led Screen

indoor rental 576mmx576mm-P3,P6.pdf

P3 indoor LED stage screen display with Low Power Consumption Meanwell Power Source



Features:

  • Compact, Reliable and Easy to Service;
  • Ultra light: only 8kg, one people could carry by one hand. It is very easy to install;
  • No need the lock bolt by unique design of cabinet connection;
  • Good performance in color uniformity, large view angle, high brightness, low fault rate and easy for maintaining;
  • Adopts Die-Casting Aluminum, with additional strengthening bracket inside, anti-tensiling and shockproof, without deformation lasting for 10 years;
  • Quick and accurate installation location type, suitable for many different installation environment;
  • Has excellent heat dissipation design and performance. It is low noise and doesn't need external fan or air-condition;
  • Ultra thin design, the LED cabinet is only 70mm in thickness;
  • Fast Maintenance, with front maintenance design, maintenance efficiency is 10 times higher than traditional method, significantly saving time needed for maintenance;
  • Cabinet size: 576mm*576mm ;



Our company:

Shenzhen LED World co.,ltd will be committing to provide more cost-effective, more energy-efficient, and greener LED optoelectronic products, contributing to building a green home.
Customer satisfaction is our prime objective and our high quality LED video display screen used in more than 140 countries and win a high reputation.
"The products we can offer you, besides outdoor full color P10 led display for advertising, also include:
1. P1.92P1.2P2.5P3P4P5P6...Indoor full color led display;
2. P5P6P6.25P6.67P8P10/P12/P12.5/P16/P20/P25...Outdoor full color led screen;
3. Indoor/outdoor/semi-outdoor single/dual color led panel etc.
Shenzhen LED World co.,ltd is a professional LED media/video display manufacturer.







Parameter:

Technical indexes Specification
Pixel pitch 3mm
Module size 192mm×192mm
Module resolution 64×64
Module density 111111dots/sqm
Cabinet Size(mm) 576x576x80
Pixel configuration RGB,3 in 1
Red wavelength 625±2nm
Green wavelength 525±2nm
Blue wavelength 470±2nm
Colors 16777216
Best viewing distance 3m---15m
Horizontal viewing angle 140°
Vertical viewing angle 120°
Maximum power consumption 1200W/sqm
Average power consumption 600W/sqm
Brightness 2500cd/sqm,adjustable
Gray scale 16bits of per color
Driving method 1/16scanning
Frame frequency 60Hz
Refresh frequency 300 Hz
Working voltage AC220V/110V±10%
IP grade IP20-45
Working temperature -20°C~80°C
MTBF More than 10,000 hours
Life span More than 100,000hours
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.
