Product Details:
Payment & Shipping Terms:
|
| System Working Environment Humidity: | 10%-90%RH | Color Temperature: | 5600K±500 |
|---|---|---|---|
| Module Size(H*W): | 192mm*192mm | Encapsulation: | SMD3528 Black |
| Pixel Pitch: | 6mm | Pixel Density: | 27777dots/M2 |
| Average Power Consumption: | 400W/M2 | Refresh Rate: | ≥1200Hz |
| High Light: | Advertising Led Display,Fixed Installation Led Display |
||
Indoor fixed led display_201905211023311.pdf
P6 SMD3528 black Indoor Fixed LED Display 1/8 scan 192x192 module front service
Application:
Our full color LED display are widely used in public facilities,HR market,massage room,plaza,Outdoor Signage and advertisement,feast,ticket center,trade fair,night club,Internet bar,station waiting area,commercial real estate,bar,stores hospitals,stadium,mansion video wall and so on .
Features:
Parameter:
| Item | Parameter |
| Pixel Pitch | P6mm |
| Encapsulation | SMD3528 black |
| Pixel Configuration | 1R1G1B |
| Driver Method | Scan1/8 |
| Color Match | R:G:B=3:6:1 |
| Module Size(H*W) | 192mm*192mm |
| Module Resolution(H*W) | 32*32dots |
| Cabinets Size(H*W) | 576*768mm |
| Pixel Density | 27777dots/M2 |
| Modules Weight | 15kg |
| Cabinet Material | Iron |
| Maintenance | Front service |
| Average Power Consumption | 400W/M2 |
| Max. Consumption | 1200W/M2 |
| Brightness | ≥2000CD/M2 |
| View Angle | H 120° /V 120° |
| Refresh Rate | ≥1200Hz |
| Frame Frequency | ≥30Hz |
| Color Depth | 14bit |
| Voltage Input | AC110V/220V±15% 40~65HZ |
| IP Rating | IP31(front/back) |
| Operating Temperature | -20ºC~60ºC , storage for :-30ºC~+90ºC |
| System Working Environment Humidity | 10%-90%RH |
| Life Span(Hours) | ≥55,000Hours |
| Best View Distance | 3-105meter |
| Color Temperature | 5600K±500 |
| Power Supply | G-energy(CE/UL) |
| Control Distance | <100meter by Internet Cable(without Relay); Fiber Cable > 500 meters |
| No-malfunction time(Avg.) | >5000hours |
| Control system | Linsn/Novastar |
| Compliant standard | CE, ROHS.ETL,UL.TUV.CCC,EMC |
| Information Sources | Many kinds of signal access: can input TV signals , DVD signals , DVI, S-VIDEO, RGB, VGA, and so on. |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |
