P2 Full Color LED Display Indoor With 60Hz Frequence Linsn / Nova System

P2 Full Color LED Display Indoor With 60Hz Frequence Linsn / Nova System
P2 Full Color LED Display Indoor With 60Hz Frequence Linsn / Nova System P2 Full Color LED Display Indoor With 60Hz Frequence Linsn / Nova System

Large Image :  P2 Full Color LED Display Indoor With 60Hz Frequence Linsn / Nova System

Product Details:
Place of Origin: China
Brand Name: Shenzhen LED World
Certification: CE,RoHS,FCC
Model Number: LW-VI 2
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: Negotiation
Packaging Details: Carton/Plywood case/Flight case etc.
Delivery Time: 12-20 working days after received your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5,00 square meters per month
Detailed Product Description
Size Of Module: 160mm X 160mm Size Of Cabinet: 480mm X 480mm X 78mm
Brightness: >1000cd/sq.m Working Voltage: AC220V/110V±10%
Data Transafer Method: RJ45 Working Humidity: 10% ~ 90%
Gray Scale: 65536 Maximum Power Consumption: 600W/sq.m
Viewing Angle: 140 /140 Material Of Cabinet: Die-casting Aluminum
High Light:

led full color screen

,

commercial led display

Indoor P2 Full Color LED Display with 60Hz frequence Linsn and nova system



Features:

  1. The die-cast aluminum cabinet is very light, saving transportation costs and easy to install ;
  2. Using magnet design structure, you can front and rear maintenance, saving the space behind the screen also;
  3. 4: 3 and 16: 9 design ratio, can be a perfect replacement LCD ;
  4. Dustproof design, protection class IP43 ;

Application:

      Our high-definition small-pitch display used in conference rooms, shopping malls, surveillance security, military bases, high-speed rail stations, cinemas, banks, airports, 4S shops, hospitals, government projects and so on .



Parameters:

Item Pixel pitch 2.0mm
Module Pixel Configuration 1R1G1B
LED component SMD1010
Size of module 160mm x 160mm
Resolution of module 80x80
cabinet Size of cabinet 480mm x 480mm x 78mm
Resolution of cabinet 240x240
Material of Cabinet Die-casting Aluminum
Weight of Cabinet about 7KG/cabinet
Electricity parameter Brightness >1000cd/sq.m
Density 250000dots/sq.m
Best viewing angle 140 /140
Best viewing distance 1.5-20M
Maximum power consumption 600W/sq.m
Average power consumption 300W/sq.m
Driving method 1/16 scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >3000Hz
IP grade IP31
Life Span 100,000 hours
Data transafer method RJ45
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.





Our service:

  1. Customer can send your engineer who has electronic and computer knowledge to our factory for the operation and maintenance training;
  2. maintainance Free:if you find the product has any problems ,pls kindly contact me;
  3. What we show is some of our current models, welcome to give us your own ideas;
  4. We will delivery goods as you demand ,you can choose the cheaper and more convenient way;
  5. Warranty: Two-Five Years, a little investment for longer warranty time
  6. Our goal is to provide the highest value of the service and professional solutions to our customers.Our team design and make solutions based on different requirements from different customers, any special design we can do, what you can think is what we can do;
