Ultra Thin Flexible Led Curtain Display P8 1/4 Scan 16 Constant Current Driving

Ultra Thin Flexible Led Curtain Display P8 1/4 Scan 16 Constant Current Driving
Ultra Thin Flexible Led Curtain Display P8 1/4 Scan 16 Constant Current Driving Ultra Thin Flexible Led Curtain Display P8 1/4 Scan 16 Constant Current Driving Ultra Thin Flexible Led Curtain Display P8 1/4 Scan 16 Constant Current Driving Ultra Thin Flexible Led Curtain Display P8 1/4 Scan 16 Constant Current Driving

Large Image :  Ultra Thin Flexible Led Curtain Display P8 1/4 Scan 16 Constant Current Driving

Product Details:
Place of Origin: China
Brand Name: Shenzhen LED World
Certification: CE, ROHS , CCC , FCC
Model Number: LW-F8
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: Carton/wooden case/Flight case etc.
Delivery Time: 7- 18 working days
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram,
Supply Ability: 5,000 pcs per month
Detailed Product Description
Pixel Pitch: 8mm Pixel Density: 15625 Dots/m2
Pixels/module: W:32 Dots X H:16 Dots Module Size: W:256mm X H: 128mm X T1.6mm (with Magnets
Weight Of Module: 0.1 Kg Bending Radian: ≤120° ( Advice 90°)
Bending Times: <1000 Times Drive Model: 16 Constant Current Driving
Methods: 1/4 Scan Votage: DC 5v ± 10%
Maximum Current: 5A
High Light:

Advertising Led Display

,

Indoor Led Display Screen

P8 1/4 scan flexible led curtain display 256mm X 128mm untra thin





P8 1/4 scan flexible led display feature:

  • Durable soft rubber module, anti-static electricity
  • Integrated SMD,IC, Circuit for easy maintenance and heat dissipation
  • Easily achieve M shape,S,concave,convex and cylinder shape ect
  • LED board front replacement,enable fast maintainence during event
  • Only 7.0cm thickness while including electronic box
  • Multiple solution for various applications,as well as customized other shapes



P8 1/4 scan flexible led display Parameter:



Pixel pitch 8mm
Pixel density 15,625 dots/m2
Pixels/module W:32 dots x H:16 dots W:32 dots x H:16 dots
Module size W:256mm x H: 128mm x T1.6mm (with magnets 16mm) W:256mm x H: 128mm x T1.6mm (with magnets 16mm)
Weight of module 0.1 kg
Bending radian ≤120° ( advice 90°)
Bending times <1000 times
Drive model 16 Constant Current Driving
Scan 1/4 S
Votage DC 5v ± 10%
Maximum current 5A
Maximum power consumption 25W
Port of power VH4
Port of signal HUB75D (IDC16)
Brightness ≥2500 cd/m2
Color temperature 9000 ± 500K
Viewing angle H/V 120°
Best viewing distance ≥8m
Grey level ≥14 Bit
Refresh rate ≥1920 Hz
Lift time 50,000 hours
Operating temperature -20° C ~ +50° C
Operating humidity -40° C ~ +80° C
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.





FQA:

1. Besides this product, may I have other options?

Yes, my dear friend. Many thanks for finish the details of this product. If it is not what you're looking for, you can also choose other items;we have HD indoor led display, full color for outdoor and indoor;Different cabinet, Steel Cabinet, Aluminum Cabinet, Die Cast Aluminum Cabinet;The pixel pitch is from 1.5mm to 20mm;We also have LED advertising player and kinds of video processor
2. What s best size of outdoor rental led display?

The best aspect ratio of outdoor rental led display are W16:H9 or W4:H3
3. What is front maintenance, what is rear maintenance?

How to choose the best servicing model for your LED display system?
Front maintenance has two means to achieve: module front maintenance cabinet front maintenance;
For asynchronous control: We use Onbon, or Xixun control system.
