Dustproof Outdoor Fixed LED Display Board SMD P5 1R1G1B Low Power Consumption

Dustproof Outdoor Fixed LED Display Board SMD P5 1R1G1B Low Power Consumption
Dustproof Outdoor Fixed LED Display Board SMD P5 1R1G1B Low Power Consumption

Large Image :  Dustproof Outdoor Fixed LED Display Board SMD P5 1R1G1B Low Power Consumption

Product Details:
Place of Origin: China
Brand Name: Shenzhen LED World
Certification: CE,RoHS,FCC,CCC
Model Number: LW-FO 5
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: negotiable
Packaging Details: Carton/Plywood case etc.
Delivery Time: 20 days after receiving the deposit
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5,000 square meters per month
Detailed Product Description
Driver Scan: 1/8 Scan Cabinet Weight: 38KG Per Cabinet
Brightness: >5500cd/㎡ Viewing Distance: >5m
Cabinet Material: Cold Rolled Steel Or Aluminum Model No: LW-FO 5
Pixel: 1R1G1B Operating Humidity: 10% - 90%
Gray Scale: Red, Green And Blue Each 16K IP Grade: Front IP65,back IP54
High Light:

led advertising board

,

high brightness led display

P5 Dustproof Outdoor Fixed LED Display Board SMD Low Power Consumption





Features:

  • Supporting many play files: videos, texts, pictures, graphics, PPT, Flashes and any sources from TV, VCD, DVD and so on
  • Low power consumption and fine heat release
  • Super wide viewing angle increasing its value by covering more audience
  • No deformation under sunlight by the use of anti-UV modules
  • High protection grade of IP65 achieved by patented mask design with waterproof and dustproof function
  • Stable Good quality: we have stable raw materials suppliers such as The lamp; the IC; the power supply; the control system etc.



Parameter:



Items Parameter
Model No LW-FO 5
Pixel 1R1G1B
Configuration SMD2727
Driver Mode 1/8 scan
Pixel Pitch 5mm
Pixel Density 40,000
Module Size(mm) 160x160
Pixels/Module 32x32
Cabinet Size(mm) 960x960 or customized
Pixels/Cabinet 192x192
Cabinet Weight 38KG
Brightness >5500cd/㎡
Viewing Distance >5m
Power Max: 1300
Consumption(W/㎡) Ave: 300
Viewing Angle H: 120°; V: 120°
Cabinet Material Cold Rolled Steel or aluminum
Refresh Rate 300-3000HZ adjustable
LED Life 100,000 hours
Supply Voltage AC220V/50HZ; AC110V/60HZ
Operating Temperature -20℃ ~ +50℃
Operating Humidity 10% - 90%
Gray Scale Red, Green and Blue each 16K
Display Color 4096 Billion
IP grade Front IP65,back IP54
Display Capability Text, Graph and Video
Compliant Standard CCC,CE,RoHS,FCC





Training:

  • We offer training for free.
  • Customers can send your engineer who has electronic and computer knowledge to our factory for the operation and maintenance training.
  • We also provide the operation manual, software, and so on. Any associated drawing of product and structure and some other professional suggestion will be provided too.



Installation:
The user's manual, instruction video, professional CAD installation drawing, and other needed engineering drawings will be provided.
We only offer the drawings, and you can show the drawing to your local steel structure factory, and they will weld it for you at site. On one hand, it's not cost-effective for you to ship the steel structure from China. On the other hand, we are impossible to offer you exact steel structure without welding at site.





LED World Service:

1, Specific, dedication, professional. It takes nearly 11 years to sharpen a sword. Most of people are seeing we are doing the common products. No! The knowledgeable people or customers who have worked with us together know how our quality is .

2, To meet customers needs. We are able to modify the details of cabinets, adopting advanced technology to update the visional effect.

3, Perfect service. We discuss about product details, solutions, logistics and after-sale service with fluent English communication with customers from A to Z. To make customers feel happy, relieved, free from worry.

4, To help customers make money. Careful inspection, no spares and accessories missed delivery. Let customers save a lot of trouble, save time and effort to maintain old customers/clients, and have more time to develop new customers.



Package:



Dustproof Outdoor Fixed LED Display Board SMD P5 1R1G1B Low Power Consumption 0
