Product Details:
Payment & Shipping Terms:
|
IP Grade: | IP65 Or IP67 | Configuration: | SMD3535 |
---|---|---|---|
Cabinet Weight(: | 26 KG | Viewing Distance: | >5m |
Drive Model: | 1/4 | Pixel Pitch: | 5mm, 8mm, 10mm |
Function: | Stage | Cabinet Material: | Alloy Die Casting |
High Light: | SMD3535 Outdoor Advertising Led Screen,Church Stage Outdoor Advertising Led Screen,1300W Waterproof Advertising Led Display |
Large Full Color Outdoor Advertising Led Screen For Church Or Stage With High Waterproof Grade
Features:
Specification:
Technical Specifications: | |||
Pixel | 1R1G1B | 1R1G1B | 1R1G1B |
Configuration | SMD2727 | SMD3535 | SMD3535 |
Pixel Pitch | 5mm | 8mm | 10mm |
Pixel Density | 40,000 | 15,625 | 10,000 |
Module Size(mm) | 320x160 | 320x160 | 320x160 |
Pixels/Module | 64x32 | 40x20 | 32x16 |
Cabinet Size(mm) | 960x960 | 960x960 | 960x960 |
Pixels/Cabinet | 192x192 | 120x120 | 96x96 |
Cabinet Weight | 28KG | 28KG | 28KG |
Brightness | 5000cd/㎡ | 5000cd/㎡ | 6500cd/㎡ |
Viewing Distance | >5m | >8m | >10m |
Power | Max: 1300 | Max: 900 | Max: 900 |
Consumption(W/㎡) | Ave: 430 | Ave: 300 | Ave: 300 |
Driver Mode | 1/8 scan | 1/5 scan | 1/2 scan |
Viewing Angle | H: 140°; V: 120° | ||
Cabinet Material | Alloy die casting | ||
Refresh Rate | 1920-3800HZ adjustable | ||
LED Life | 100,000 hours | ||
Supply Voltage | AC220V/60HZ; | ||
Operating Temperature | -20℃ ~ +50℃ | ||
Operating Humidity | 10% - 90% | ||
Gray Scale | Red, Green, and Blue each 16K | ||
Display Color | 4096 Billion | ||
IP Rating | Front IP65 | ||
Display Capability | Text, Graph, and Video | ||
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. |
Product-related:
LED Display /LED display screen/LED sign/LED video wall
1. Model No.: P1.56,P1.66,P1.9,P2.0, P2.5, P3, P4, P5, P6, P7.62, P8, P10, P12, P12.5, P13.33, P16, P20, P25 etc
2. Display Color: 256*256*256
3. LED Chips: Opto, Epistar, Silan, Huacan, Sanan
4. Raw Materials: Toshiba IC, MBI IC, Chuanglian Power Supply, Meanwell Power Supply, Meanwell fans, ADDA fan, Beijing glue, Korean glue.
5. Cabinet: Standard cabinet, simple cabinet, customized cabinet, a cabinet for rental, Iron or Aluminum cabinet, a cabinet for front maintenance, cabinet with lock, special cabinet with Southco Lock, for hung and rental and etc.
6. Package: Flight case, wooden box package & carton box and etc.
7. Guarantee: 2 year
Application:
It is widely used in large glass curtain walls, cylindrical, curved, S-shaped, and other special-shaped curtain wall places, street shops, stages, conferences, weddings, studios, and other large entertainment venues.
Details:
