Product Details:
Payment & Shipping Terms:
|
Pixel Density: | 43264 Pixels/sqm | Voltage: | DC5V |
---|---|---|---|
Cabinet Weight(: | 7.5 KG | Viewing Distance: | >4m |
Cabinet Material: | Alloy Die Casting | Function: | Stage |
Configuration: | SMD2727 | Brightness: | 6000 Nits |
High Light: | SMD2727 led wall video background,Alloy led wall video background,6000 nits video wall background |
Small Rental SMD LED Video Wall Background For Advertising At The Stage Or Meeting Room
Features:
1, High brightness
2, We display support automatically or manually adjust the brightness of the LED display screen;
3, color and brightness of synchronous adjustment, make the image more exquisite realistic;
4, dual power supply and backup data control signals;
5, Good waterproof IP65, suit to any weather,anti-corrosion, long life span;
6, Anti UV, anti-deformation module suite to protect the screen body deformation;
Specification:
1. CE,FCC,RoHS,C-Tick approved
2. High quality, High definition, High refresh
3. Superior uniformity, Good display effect
4. 2 years warranty, best after-sales service
5. Video, flash, animation, graphic, text available;
6. Installation structure drawing offered FOC;
7. Factory visiting and inspecting is welcome;
8. OEM service offered;
9. Models available:
Indoor led display-P2.5mm, P3mm,P3.91, P4mm,P4.81, P5mm, P6mm,P6.25,P10mm etc.
Outdoor led display-P3.91mm,P4.81,P5mm, P6mm, P6.25,P8mm, P10mm, P16mm,P20mm etc.
Parameter:
Module Parameters
|
|
Pixel Pitch
|
4.81mm
|
Pixel Configuration
|
1R1G1B
|
Pixel Density
|
43264 Pixels/sqm
|
LED Lamp
|
SMD2727
|
Module Size
|
250*250mm
|
Module Resolution
|
(W)52*(H)52 Pixels
|
Working Voltage
|
DC5V
|
Scan Mode
|
Constant Current 1/7 Scan
|
Port Type
|
HUB75
|
Screen Parameters
|
|
Cabinet Size
|
(W)1000*(H)1000*(D)150mm
|
Cabinet Material
|
Aluminum/Iron
|
Weight
|
35KG/sqm or 45KG/sqm
|
Cabinet Resolution
|
(W)208*(H)208 Pixels
|
Module Qty
|
16pcs
|
Power Supply
|
5V 60A 300W
|
Working Voltage
|
AC220V±10%
|
Max Power Consumption
|
700W/sqm
|
Ave Power Consumption
|
230W/sqm
|
Brightness
|
6000 Nits
|
Refresh Rate
|
1920Hz
|
Frame Frequency
|
60Hz
|
Grey Scale
|
14 bit
|
Brightness Level
|
256 levels
|
Best View Distance
|
5M-50M
|
View Angle
|
120°(Horizontal); 120°(Vertical)
|
Protection Degree
|
IP65
|
Working Temperature
|
-20ºC ~ +60ºC
|
Relative Humidity
|
10%-95%
|
Operation system
|
WIN7/WIN8
|
Control Method
|
Synchronous or Asynchronous
|
Control System
|
Nova/Linsn/ColorLight/Huidu
|
Control Distance
|
100M(Ethernet cable); 20KM(Optical fiber cable)
|
Input Signal
|
Composite Video, S-video, DVI, HDMI, SDI, HD-SDI
|
Out-of-Control Pixel Rate
|
≤0.01%
|
Why choose us:
1, Viewing angle, wavelength, and other optical properties; aging test LED lamps attenuation; an IC testing stand, strict control the quality of the IC ;
2, 24/7 after-sale service
3, First-rate service;
4, Our products are low consumption;
