Brightness: | >1200cd/sq.m | Material Of Cabinet: | Die-casting Aluminum |
---|---|---|---|
Average Power Consumption: | 300W/sq.m | Control Method: | Synchronization |
MTBF: | 10,000 Hours | Colors: | 256*256*256 |
Best Viewing Distance: | 2-30M | Size Of Module: | 160mm X 160mm |
High Light: | Led Stage Backdrop Screen,Stage Background Led Screen |
Features:
Our service:
Why choose us:
Parameter:
Pixel pitch | 2.5mm |
Pixel Configuration | 1R1G1B |
LED component | SMD2121 |
Size of module | 160mm x 160mm |
Resolution of module | 64x64 |
Size of cabinet | 480mm x 480mm x 78mm |
Resolution of cabinet | 192x192 |
Material of Cabinet | Die-casting Aluminum |
Weight of Cabinet | about 7KG/cabinet |
Brightness | >1200cd/sq.m |
Density | 160000dots/sq.m |
Best viewing angle | 140 /140 |
Best viewing distance | 2-30M |
Maximum power consumption | 600W/sq.m |
Average power consumption | 300W/sq.m |
Driving method | 1/32 scan |
Control method | Synchronization |
Gray scale | 65536 |
Colors | 256*256*256 |
Working voltage | AC220V/110V±10% |
Working temperature | -20ºC~+50ºC±10% |
Working humidity | 10% ~ 90% |
MTBF | 10,000 hours |
Frame frequence | 50/60Hz |
Refresh frequence | >3000Hz |
IP grade | IP31 |
Life Span | 100,000 hours |
Data transafer method | RJ45 |
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. |
