Product Details:
Payment & Shipping Terms:
|
Cabinet Weight: | 22kg | Pixels: | SMD 3in1(3535) |
---|---|---|---|
Cabinet Material: | Die-Casting Aluminium | Cabinet Resolution: | 96×96dots |
Power(maximum): | 620W/sq.m | Temperature Range: | -15~60°C |
Gray Scale/color: | >16.7M | Pixel Pitch: | 10mm |
High Light: | Led Stage Backdrop Screen,Stage Background Led Screen |
Features:
Why choose us:
Application:
It can be widely used in schools,Entertainment centers,grogshop,tennis,company presentations,press conference,massage room,pedestrian streets,exhibition, conference,Volleyball and Basketball courts,
advertisement,parking garage,swimming pools,Amusement parks and so on .
Parameter:
Items | Parameter |
No. | LW-RO10 |
Pixel pitch | 10mm |
Pixels | SMD 3in1(3535) |
Pixel density | 10000pixels/sq.m |
Cabinet resolution | 96×96dots |
Cabinet dimensions | 960mm×960mm×80mm |
Cabinet material | Die-Casting Aluminium |
Cabinet weight | 22kg |
Module size | 320mm×160mm |
Module resolution | 32dot×16dot |
Brightness | >6000nits |
Driving method | Constant current |
1/4scan | |
Refresh frequency | ≥200Hz |
Gray level | 1024~16384 |
Gray scale/color | >16.7M |
Frame frequency | >60Hz |
Viewing angle | 120° |
Power(maximum) | 620W/sq.m |
Ingress protection | IP65 |
Temperature range | -15~60°C |
Humidity range | 10%~90%RH |
Control system | Synchronous control systemAsynchronous control system |
Input signal | AV S-VIDEO VGA DVI HDMI YPBPR SDI DP |
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. |
