3G / WIFI / GPS IP65 P5 Outdoor Full Color LED Display With Meanwell Power Supply

3G / WIFI / GPS IP65 P5 Outdoor Full Color LED Display With Meanwell Power Supply
3G / WIFI / GPS IP65 P5 Outdoor Full Color LED Display With Meanwell Power Supply 3G / WIFI / GPS IP65 P5 Outdoor Full Color LED Display With Meanwell Power Supply 3G / WIFI / GPS IP65 P5 Outdoor Full Color LED Display With Meanwell Power Supply

Large Image :  3G / WIFI / GPS IP65 P5 Outdoor Full Color LED Display With Meanwell Power Supply

Product Details:
Place of Origin: China
Brand Name: Shenzhen LED World
Certification: CE,RoHS,FCC,CCC
Model Number: LW-RO 5
Payment & Shipping Terms:
Minimum Order Quantity: 1 Square Meter
Price: Negotiable
Packaging Details: Carton/Plywood case/Flight case etc.
Delivery Time: 12~18 days after receiving the deposit
Payment Terms: T/T, Western Union
Supply Ability: 2000 Sqm/Month
Detailed Product Description
Thickness Of Module (mm): 17.05(No Magnet) Size Of Cabinet(mm): 640*640
Working Voltage(V): AC220V±10% Scan And Control Method: 1/8 Synchronous Control
Level Of Gray: 65536 Size Of Module(mm): 320*160 Mm
Driving Method: Constant Current Driving Best Viewing Angle: 160(W) 120(H)
High Light:

led full color screen

,

commercial led display

P5 outdoor Full Color LED Display with meanwell power supply 3G / WIFI / GPS


P5 outdoor Full Color LED Display features:

  • P5 outdoor fixed LED screen iron cabinet can be customized ;
  • P5 LED panel is more clearer than P6,P8,P10 ;
  • IP65 protection grade, durable nature to enable the OA LED screen working in all weather outdoor environments;
  • Made with SMD2727 led lamps, high contrast and wide view angle up to 140/140(H/V);
  • Cabinet size is customizable without any extra cost;
  • LED unit module board &IC
  • The quality of LED module directly affects displaying effect.
  • LED module consists of LED lamps, driven IC and PCB circuit board.
  • IC: MBI 5124
  • LED encapsulation : Nation Star;
  • Durable & stable;
  • widely used in building showing;



P5 outdoor Full Color LED Display  parameter:

Module Parameter NO. P5 P8
Size of Module(mm) 320*160 256*128
Pixel Density(dots/m²) 40000 dots/m² 15625 dots/m²
Pixel Pitch(mm) 5mm 8mm
LED Encapulation SMD2727 SMD3535
Resolution of Module(dots) 64(W)*32(H) 32(W)*16(H)
Thickness of Module (mm) 17.05(No magnet) 17.05(No magnet)
Weight of Module (Kg) 0.5 0.343
Driving Method Constant Current Driving Constant Current Driving
Equilibrium Brightness(CD//m²) ≥7000 CD/m² ≥6500 CD/m²
Bracket Size(mm) 160*160 256*128
320*160 256*256
Cabinet Size of Cabinet(mm) 640*640 768*768
512*512
Power Supply Mode 5V/40A*1PC 5V/40A*1PC
Best Viewing Distance(m) 5-100m 8-100m
Best Viewing Angle 160(W) 120(H) 160(W) 120(H)
Storage Temperature(ºC) -35ºC ~ +85ºC -35ºC ~ +85ºC
Working Temperature(ºC) -40ºC ~ +50ºC -40ºC ~ +50ºC
Relative Humidity 10%-95% 10%-95%
Power Supply Working Voltage(V) AC220V±10% AC220V±10%
Average Power Consumption(W/m²) ≤500 W/m² ≤380 W/m²
Max Consumption(W/m²) ≤1000 W/m² ≤760 W/m²
Control System Scan and control Method 1/8 Synchronous Control 1/4 Synchronous Control
Driving Components Constant current Driving Constant current Driving
Technical Parameters Refresh Frequency ≥1920 Hz/Sec ≥600 Hz/Sec
(HZ)

Frame Frequency ≥60 HZ/Sec ≥60 HZ/Sec
(HZ)
Level of Brightness/Color RGB256 RGB256
Level of Gray 65536 65536
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Trade term:

  • Trade Terms:
  • Service: Provide free technology support by phone and e-mail;
  • Shipping port: Shenzhen, China;
  • Packing: Anti-shaking wooden package or Air Flight Case;


Our service:

  • 2 years warranty offered;
  • Customer can send your engineer who has electronic and computer knowledge to our factory for the operation and maintenance training;
  • LED WORLD can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display;
  • Maintenance and Consultation
  • (1) We provide full maintenance for a lifetime and charge for the raw materials only.
  • (2) We also provide lifetime consultation by E-mail, call, MSN or other ways for free.



P5 outdoor Full Color LED Display  package:
3G / WIFI / GPS IP65 P5 Outdoor Full Color LED Display With Meanwell Power Supply 0
