Pixels Densit4mmy: | 62500dots/m2 | Input Voltage: | AC220V/110V,50HZ/60HZ (±10%) |
---|---|---|---|
Storage Temperature: | -35℃~+85℃ | Working Temperature: | -20℃~+50℃ |
Panel Area: | 0.262 Sq. M | Cabinet Resolution: | 128dots(W)*128dots(H) |
Brightness: | 800-1000 Nits | LED Per Sq. Meter: | 62, 500 |
Scan Mode: | 1/16 Scan | Humidity Operating: | 10% ~ 90% RH |
High Light: | SMD2121 Flexible LED Display,1000nits Flexible LED Display,AC220V Indoor Led Display Board |
P4 Flexible Indoor Advertising Display 1000 Nits Brightness With Long Using Life
P4 portable indoor LED display feature:
1. Uniform color and high contrast ratio,bringing up fresh and natureal image ;
2. Low power consumption and fine heat release ;
3. Super wide viewing angle increasing its value by covering more audience ;
4. No deformation under sunlight by the use of anti-UV modules ;
5. High protection grade of IP65 achieved by patented mask design with waterproof and dustproof function ;
6. Safe and reliable operation ensured by stable signal and power supply .
P4 LED display parameters:
Module Parameters | ||||
Module Type | Indoor P4 | |||
Pixel Pitch | 4mm | |||
LED Type | RGB 3in1 | |||
LED Mode | SMD2121 | |||
Module Size | 256mm*128mm | |||
Module Resolution | 64dots(W)*32dots(H) | |||
Driving Type | IC2037 | |||
Scan Mode | 1/16 scan | |||
Cabinet Parameters | ||||
Cabinet Size | 512mm*512mm | |||
Cabinet Resolution | 128dots(W)*128dots(H) | |||
Module Quantity | 8pcs | |||
Cabinet Material | die-casting aluminum | |||
Cabinet Weight | 7kg | |||
Screen Parameters | ||||
Pixels Density | 62500dots/m2 | |||
Input Voltage | AC220V/110V,50HZ/60HZ (±10%) | |||
Brightness of White | 800-1000cd/m2 | |||
Best Viewing Angle | 160°(W) 120°(H) | |||
Best Viewing Distance | ≧4m | |||
Fresh Requency | 1920HZ | |||
Storage Temperature | -35℃~+85℃ | |||
Working Temperature | -20℃~+50℃ | |||
MTBF | ≧10,000H |
FQA:
Q1: What's the pixel pitch for Outdoor LED Display Screen?
A1: Outdoor(P3mm/P3.91mm/P4mm/P4.81mm/P5mm/P6mm / P8mm/P10mm)
Q2: What's the pixel pitch for Indoor LED Display Screen?
A2: Indoor(P1.667mm/P1.875mm/P2mm/P2.5mm/P2.976mm/P3mm/P3.91mm/P4mm/P4.81mm/P5mm/P6mm / P8mm/P10mm)
Q3: What's Delivery Time?
A3: Usually, Common Product has Stock, shipping out within 7 days after deposit.
The customized product needs 15~25 days after getting a deposit according to the project size.
Q4: How to choose a proper led screen for you?
A4: You just need to think of 3 simple questions in your head before you buy a led screen.
Will you use it indoors or outdoor?
Is it for rental use(need to be moved from one place to another place very often) or for fixed installation (to be installed in one place forever).
What is the approximate size of the led screen you needed? what are the height and length?
Q5: How to install it after we receive it?
A5: We will offer instructions to guide you on installation, and also software setting up photos or steel construction drawings.
Application:
1. Business Organizations: Supermarket, large-scale shopping malls, star-rated hotels, travel agencies.
2. Financial Organizations: Banks, insurance companies, post offices, hospital, schools.
3. Public Places: Subway, airports, stations, parks, exhibition halls, stadiums, museums, commercial buildings, meeting rooms.
4. Entertainments: Movie theaters, clubs, stages.
