| Life Time: | 100,000 Hours | Vertical Viewing Angle: | 160 |
|---|---|---|---|
| Gray Scale: | Red, Green, And Blue Each 16K | Maximum Power Consumption: | 800 |
| Viewing Angle: | H: 120°; V: 120° | Cabinet Size: | 576 X 576mm |
| Average Power Consumption: | 270W | Display Capability: | Text, Graph, And Video |
| High Light: | 270W Indoor Advertising Led Display,AC220V Indoor Advertising Led Display,Aluminum Indoor Smd Led Display |
||
Light Weight Indoor Advertising Led Display Screen Front And Back Service For Rental
Outdoor led screen specification:
| Items | P4mm | P5mm | P6mm | P8mm | P10mm |
| Pixel | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Configuration | SMD2525 | SMD2727 | SMD3535 | SMD3535 | SMD3535 |
| Pixel Pitch | 4mm | 5mm | 6mm | 8mm | 10mm |
| Pixel Density | 62500 dots/m2 | 40000 dots/m2 | 27777 dots/m2 | 15625 dots/m2 | 10000 dots/m2 |
| Module Size(mm) | 256x128 | 160x160 | 192x96or 192x192 | 256x128 | 320x160 |
| Pixels/Module | 64x32 | 32x32 | 32x16 or 32x32 | 32x16 | 32x16 |
| Cabinet Size(mm) | 768x768 | 960x960 | 960x960 | 1024x1024 | 960x960 |
| Pixels/Cabinet | 192x192 | 192x192 | 160x160 | 128x128 | 96x96 |
| Cabinet Weight | 24KG | 36KG | 36KG | 41KG | 36KG |
| Brightness | >5500cd/ | >5500cd/ | >6000cd/ | >5000cd/ | 7000cd/ |
| Viewing Distance | >4m | >5m | >6m | >8m | >10m |
| Power | Max: 1300 | Max: 1300 | Max: 1300 | Max: 1000 | Max: 1000 |
| Consumption(W/) | Ave: 300 | Ave: 300 | Ave: 260 | Ave: 260 | Ave: 300 |
| Driver Mode | 1/8 scan | 1/8 scan | 1/4 scan or 1/8 | 1/4 scan or 1/8 | 1/2 scan |
| Viewing Angle | H: 120°; V: 120° | ||||
| Cabinet Material | Cold Rolled Steel or aluminum | ||||
| Refresh Rate | 300-3000HZ adjustable | ||||
| LED Life | 100,000 hours | ||||
| Supply Voltage | AC220V/50HZ; AC110V/60HZ | ||||
| Operating Temperature | -20ºC ~ +50ºC | ||||
| Operating Humidity | 10% - 90% | ||||
| Gray Scale | Red, Green, and Blue each 16K | ||||
| Display Color | 4096 Billion | ||||
| IP Rating | Front IP65 | ||||
| Display Capability | Text, Graph, and Video | ||||
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |||||
Our company advantage:
1. Good quality and price
The price is 10% lower than the market because of the introduction of a fully automatic production line with the characteristics of reducing the cost of labor and management;
2. Lightweight with no rust
It can use aluminum cabinet greatly saving fright cost and conveniently installing;
3. Stable performance
our most basic guarantee: the aging time exceeding 24 hours. Malfunction dot rate less than 0.0001. MTBF more than 1000 hours;
4. Best quality LED chip tube
the GREE, SILAN, OPTO, EPISTAR assuring high brightness and long lifespan;
5. Supporting different formats of images and videos
Flash, WAV/MIDI, Videos from TV, and other equipment.
Our service:
1, Two years warranty;
2, Design the framework structure to install our led products with technical drawing;
3, Provide unique and professional solutions based on customer's requirements;
4, LED WORLD provides 1% spare parts freely, including LED module, power supply, fan, receiving card, LED
lamps and other related parts;
5, We provide remote control service through the internet to achieve real-time service, which will shorten the
customer problem solving;
6, Reply inquiries in 24 hours;
Training:
We offer training for free.
Customer can send your engineer who has electronic and computer knowledge to our factory for the operation and maintenance training.
We also provide the operation manual, software, and so on. Any associated drawing of product and structure and some other professional suggestion will be provided too.
